Product Details:
|
| Condition: | New | Max.torque: | 50 KN.m |
|---|---|---|---|
| Max. Drilling Diameter: | 1200 Mm | Max. Drilling Depth: | 24m |
| Speed Of Rotation: | 7-40rpm | Max. Cylinder Stroke: | 1100mm |
| Main Winch Line Speed: | 48 M/min | Main Winch Pull Force: | 75 KN |
| Max. Operating Height: | 7181 Mm | Max. Operating Width: | 2300mm |
| Max. Transport Weight: | 7t | Xcavator Size: | 14 T-24 T |
| Highlight: | 24m Rotary Piling Rig,High Quality Rotary Piling Rig,1200mm Rotary Piling Rig |
||
Technical Specification
| Rotary Drilling Rig Model | KR50A | ||
| Excavator Size | 14t-16t | 20t-23t | 24t+ |
| Max. torque | 50 kN.m | 50 kN.m | 50 kN.m |
| Max. drilling diameter | 1200 mm | 1200 mm | 1200 mm |
| Max. drilling depth | 16 m | 20 m | 24 m |
| Main winch pull force | 70 kN | 75 kN | 75 kN |
| Main cylinder trip | 1100 mm | 1100 mm | 1100 mm |
| Auxiliary winch pull force | 65 kN | 65 kN | 65 kN |
| Main winch speed | 48 m/min | 48 m/min | 48 m/min |
| Mast inclination(Lateral) | ±6° | ±6° | ±6° |
| Mast inclination(Forward) | -30°~ ﹢90° | -30°~﹢90° | -30°~﹢90° |
| Working speed | 7-40rpm | 7-40rpm | 7-40rpm |
| Min. radius of gyration | 2800mm | 2950mm | 5360mm |
| Max. pilot pressure | 31.5Mpa | 31.5Mpa | 31.5Mpa |
| Operating height | 8868mm | 9926mm | 11421mm |
| Operating width | 2600mm | 2800mm | 3300mm |
| Transport height | 2731mm | 3150mm | 3311mm |
| Transport width | 2600mm | 2800mm | 3300mm |
| Transport length | 10390mm | 11492mm | 12825mm |
| Transport weight | 6.1t | 6.5t | 7t |
| Remark | Restructuring big arm | Restructuring big arm | Restructuring big arm |
Why Choose Us?
1. We are the professional & trustworthy manufacturer of piling machinery in China, best quality & best service.
2. Supply professional customized service to meet all your requirements.
3. Our rotary drilling rigs have been sold to more than 7 counstries, such as Russia, Australia, Thailand, Zambia and others.
4. Competitive price.
Q1: What is the Warranty of the Rotary Drilling Rig?
The warranty period for new machine is one year or 2000 working hours, whichever comes first will be applied.
Please contact with us for detailed Warranty Regulation.
