Product Details:
|
| Max. Drilling Diameter: | 2600 Mm | Max. Torque: | 150 KN.m |
|---|---|---|---|
| Max. Drilling Depth: | 30 M | Main Winch Line Speed: | 78 M/min |
| Max. Crowd Pressure (kN): | 100 KN | Main Winch Pull Force: | 110 KN |
| Speed Of Rotation: | 6~30 Rpm | Operating Width (mm): | 3600 Mm |
| Operating Height (mm): | 13460 Mm | TOTAL Weight: | 38 T |
| Highlight: | 30m hydraulic piling rig,low head room hydraulic piling rig,tysim rig machine for piling |
||
| Performance Parameter | Unit | Value | |
| Max. torque | kN.m | 150 | |
| Max. drilling diameter | mm | 2600 | |
| Max. drilling depth | m | 30 | |
| Working speed | rpm | 6~30 | |
| Max. cylinder pressure | kN | 100 | |
| Max. hoist capacity | kN | 150 | |
| Main winch pull force | kN | 110 | |
| Main winch speed | m/min | 78 | |
| Max. cylinder stroke | mm | 3200 | |
| Mast side raking | ° | ±4.5 | |
| Mast raking forward | ° | 5 | |
| System pressure | mpa | 34.3 | |
| Pilot pressure | mpa | 3.9 | |
| Max. walking speed | km/h | 2.6 | |
| Max. pull force | kN | 230 | |
| Operating height | mm | 13460 | |
| Operating width | mm | 3600 | |
| Transport height | mm | 3835 | |
| Transport width | mm | 2600 | |
| Transport length | mm | 12628 | |
| Total weight | t | 38 | |
| Engine performance | |||
| Engine type | Cummins QSB7 | ||
| Cylinder number*cylinder diameter*stroke | mm | 6×107×124 | |
| Displacement | L | 6.7 | |
| Rated power | kw/rpm | 140/2050 | |
| Emission standard | EUⅢ | ||
| Kelly bar | |||
| Model | Interlocking | ||
| Outer diameter | φ355 | ||
| Layers*Length of each section | 4×8.5 | ||
| Max.depth | 30 | ||
Why Choose Us?
1. We are the professional & trustworthy manufacturer of piling machinery in China, best quality & best service.
2. Supply professional customized service to meet all your requirements.
3. Our rotary drilling rigs have been sold to more than 20 countries, such as Russia, Australia, Thailand, Zambia and others.
4. Competitive price.
Q1: What is the Warranty of the Rotary Drilling Rig?
The warranty period for new machine is one year or 2000 working hours, whichever comes first will be applied.
Please contact with us for detailed Warranty Regulation.
Q2: What's your service ?
We can offer professional technical support and good after-sale service to you.
Modification methods will be different according to different models and configurations of your owned excavators.
Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.
Before modifying, you need to confirm technical specification.
